Vertical Planetary Ball Mills

Shop Horizontal High Energy Planetary Mill>

Shop All Direction High Energy Planetary Mill>

Four ball grinding tanks are present on a single table in these vertical planetary ball mills. Once the turntable rotates, the tank axis here makes planetary movements, impacting the balls and samples present inside. In this manner, materials inside are eventually turned into powder. These machines are available in different capacities, as visible here.

With this high quality machine, you can easily get material mixing, sample making, fine grinding, and new product development done. Not only is this machine very efficient, but it also produces very low levels of noise. This makes it suitable to keep in a wide variety of places. Industries such as metallurgy, medical, and chemical are immensely benefited by it.

Apart from the above, the operation of our vertical planetary ball mill is really simple. You will get comprehensive instructions with every model. Low center of gravity allows it to operation in a safe manner.



Model Number
Total Volume (L)
Maximum Rotation Speed (RPM)
Power (kW)
Material Capacity (L)
Outer Dimension (mm)
MA0101
0.4
870
0.25
0.12
530*300*360
MA0102
0.2
1160
0.09
0.06
250*425*280
MA0103
1
670
0.75
0.35
760*470*600
MA0104
2
670
0.75
0.65
760*470*600
MA0105
4
670
0.75
1.3
760*470*600
MA0108
20
430
4
6
1200*790*930
MA0115
6
670
0.75
2
760*470*600
MA0122
8
580
1.5
2.5
800*560*642
MA0121
10
580
1.5
3
800*560*642
MA0123
12
580
1.5
4
800*560*642
MA0124
16
510
4
5
950*650*910
MA0125
(Special Order)
40
390
5.5
13
1400*880*1070
MA0126
(Special Order)
60
360
7.5
20
1600*1070*1250
MA0117
(Special Order)
100
240
11
35
1750*1140*1330
