MSE PRO 10g High Purity (>99.9 wt%) Graphitized Multi-Walled Carbon Nanotubes (MWCNTs) with Open Tube Ends

SKU: PO5022

  • $ 14995



ZProduct details:

High Purity (>99.9 wt%) Graphitized Multi-Walled Carbon Nanotubes (MWCNTs) with Open Tube Ends

Package size: 10 g per bottle

Graphitized Multi-Walled Carbon Nanotubes (MWCNTs) are purified under inert gas for about 20 hours thermal treatment at 2800℃. It has the highest graphite crystallization, the best electrical conductivity and the best inoxidizability. The electrical conductivity is similar to graphite powder and the ignition temperature can reach 800℃. It has both tube ends open.

Due to its high thermal and electrical conductivity, carbon nanotubes are widely used for applications such as: additives in polymers, catalysts, electron field emitters for cathode ray lighting elements, gas-discharge tubes in telecom networks, electromagnetic-wave absorption and shielding, lithium battery, sensors, reinforcements in composites and supercapacitor.

MSE Supplies offers a variety of CNT products, include CNTs powder, CNTs paste, CNTs
array, CNTs fiber, CNTs film, CNTs film adhesive tape, CNTs conductive heating coating, CNTs thermal radiation coating, CNTs transparent static conductive coating, CNTs conductive fillers, CNTs functional masterbatches, CNTs epoxy composite, etc. Please contact us for customization or bulk orders.

Specifications:

Parameter Unit SKU# PO5022
SKU# PO5023
OD nm 10-20 20-30
 Purity wt% >99.9 >99.9
Length microns 5-30 5-30
SSA m2/g >80 >90
OD=Outer Diameter                            SSA=Special Surface Area

Reference:

1. Heat-treated multi-walled carbon nanotubes-supported (Fe,Co,Ni)-coordinated polyporphyrin: A robust air cathode catalyst for rechargeable zinc-air batteries, Electrochim. Acta, Volume 358, 20 October 2020, 136918

2. Multi-walled carbon nanotubes acting as free radical scavengers in gamma-irradiated ultrahigh molecular weight polyethylene composites, Carbon, Volume 50, Issue 7, June 2012, Pages 2442-2452
