MSE PRO 4L (4,000 ml) Y-Stabilized Zirconia Milling Jar for Planetary Mills

Specifications for Zirconia Milling Jar

• Each jar set includes grinding jar, jar lid, rubber sealing gasket.

• Milling media sold separately

• Cost-effective, low wear and long lifetime.

• High specific gravity, high milling efficiency.

• Chemical resistant to acid and solvents.

• Smooth, easy to clean, minimum wearing to the equipment.

• Excellent toughness, high impact resistance, no broken beads.

• Mainly used for planetary ball mill machines.

Features of Zirconia Milling Jar

• Item No. : JA0217
• Material : Y stabilized Zirconium Oxide -ZrO₂
• Jar Volume : 4,000 ml (4L)
• Max Loading Capacity : 2/3 capacity of the grinding jar
• Density : 6.06 g/cm³
• Color : ivory white
• Shape : cylindrical
• Hardness : >89 HRA
• Abrasion Resistance : very good
• Suitable for : fibrous, abrasive samples
• Max Working Temperature : 320 ^oC
• Attachment : lid and rubber sealing gasket
• Grind Balls : zirconium oxide balls
• Grind Ball Sizes : 1 mm - 50mm beads are available

Did You Know?

A stainless steel sleeve can be added to convert to rotary mill (roller mill) application. please contact us for specific requirement.
