Antech 43L W Series, Wide-Neck Cryogenic Freezer
SKU: W380-1
Antech 43L W Series, Wide-Neck Cryogenic Freezer
Buy Antech products from MSE Supplies at the best value.
W series liquid nitrogen storage system provides ideal storage conditions for biological samples. Supported by LN2 automatic filling system and temperature & LN2 level monitoring system, W series cryogenic freezers provide all-round protection to precious sample, assisting life science research and cell therapy applications.
Based on the actual needs of users, Antech has innovatively optimized the performance, structure and control system of cryogenic freezer to meet the user's highest standard of large-capacity storage requirements.
- Multiple capacity freezers, from 175L to 600L, 2.0ml vials storage capacity from 10,000 to 40,500.
- Excellent temperature uniformity and stability, enabling samples to be stored at controlled cryogenic environment.
- Excellent vacuum performance and structural design ensure minimum liquid nitrogen consumption and lower storage costs.
- Advanced temperature, liquid level monitoring and alarm system, and can realize remote monitoring.
- Automatic supply of liquid nitrogen, safe and labor-saving.
- The liquid nitrogen supply system is controlled by multiple solenoid valves, which can effectively prevent the overflow of liquid nitrogen and sample contamination caused by high LN2 level.
- Manual filling available under special circumstances.
- Compatible with vapor phase and liquid phase storage modes, users can choose according to their needs.
- The optimized mechanism design realizes high-density storage to save space.
MSE Supplies offers a variety of Antech Products. Please contact us for more information.
Specifications:
SKU# | W380 |
LN2 Capacity | 28 L |
Inner diameter | 1000 mm |
Usable height |
785 mm |
Overall height |
1300 mm |
Weight empty | 395 kg |
Controller | Touch screen |
Voltage | 110 V / 60 Hz |
Maximum Storage Capacity:
Model | W100 | W240 | W380 | ||||
Maximum storage capacity | Liquid | Vapor | Liquid | Vapor | Liquid | Vapor | |
Straw | PETG 1/4cc straw | 180400 | 144320 | 397700 | 318160 | 639600 | 511680 |
PETG 1/2 cc straw | 80300 | 64240 | 177025 | 141620 | 284700 | 227760 | |
HSV CBS high security straws | 80300 | 64240 | 177025 | 141620 | 284700 | 227760 | |
High security CBS straws | 49500 | 39600 | 109125 | 87300 | 175500 | 140400 | |
Number of canisters (φ70mm) | 44 | 44 | 97 | 97 | 156 | 156 | |
Goblet (φ65mm) per canister | 5 | 4 | 5 | 4 | 5 | 4 | |
2ml vial | 1.2 &2ml vial | 10725 | 9900 | 26325 | 24300 | 41275 | 38100 |
Number of large rack (81/100-place box) | 7 | 7 | 19 | 19 | 30 | 30 | |
Number of small rack (25-place box) | 5 | 5 | 5 | 5 | 7 | 7 | |
2" Boxes per rack | 13 | 12 | 13 | 12 | 13 | 12 | |
5ml vial | 5ml vial (81-place) | 3969 | 3402 | 10773 | 9234 | 17010 | 14580 |
Number of racks | 7 | 7 | 19 | 19 | 30 | 30 | |
3.75" Boxes per rack | 7 | 6 | 7 | 6 | 7 | 6 | |
25ml blood bag (Pall MEDSEPTM 25 mL, OriGen CS 25) |
Numbers of blood bag | 763 | 763 | 1694 | 1694 | 2681 | 2681 |
Number of frames | 109 | 109 | 242 | 242 | 383 | 383 | |
Bags per frame | 7 | 7 | 7 | 7 | 7 | 7 | |
50ml blood bag (Fenwal 4R9951, OriGen CS 50) |
Numbers of blood bag | 476 | 476 | 1085 | 1085 | 1715 | 1715 |
Number of frames | 68 | 68 | 155 | 155 | 245 | 245 | |
Bags per frame | 7 | 7 | 7 | 7 | 7 | 7 | |
250ml blood bag (Fenwal 4R9953 & 4R5461, OriGen CS 25 or CryoMACS 50 & 250) |
Numbers of blood bag | 270 | 216 | 595 | 476 | 970 | 776 |
Number of frames | 54 | 54 | 119 | 119 | 194 | 194 | |
Bags per frame | 5 | 4 | 5 | 4 | 5 | 4 | |
500ml blood bag (Fenwal 4R9955 & 4R5462, OriGen CS 500) |
Numbers of blood bag | 210 | 168 | 475 | 380 | 760 | 608 |
Number of frames | 42 | 42 | 95 | 95 | 152 | 152 | |
Bags per frame | 5 | 4 | 5 | 4 | 5 | 4 | |
200ml blood bag (Gambro DF-200 or CryoMACS 50 & 250) |
Numbers of blood bag | 144 | 144 | 332 | 332 | 528 | 528 |
Number of frames | 36 | 36 | 83 | 83 | 132 | 132 | |
Bags per frame | 4 | 4 | 4 | 4 | 4 | 4 | |
700ml blood bag (Gambro DF-700, OriGen CS 1000 or CryoMACS 500& 750 &1000) |
Numbers of blood bag | 84 | 84 | 196 | 196 | 312 | 312 |
Number of frames | 21 | 21 | 49 | 49 | 78 | 78 | |
Bags per frame | 4 | 4 | 4 | 4 | 4 | 4 |
