IKA IC Temperature Control
SKU: 0003863001
IKA IC Temperature Control
Buy IKA products from MSE Supplies at the best value.
MSE Supplies is an authorized distributor of IKA.
Product Details
Item number: 0003863001
The IC control immersion circulator has an extended temperature range for tempering fluids in open and covered water baths up to 250 °C. The control circulator has a Wireless Controller (WiCo). The TFT display shows all relevant process parameters. The internal temperature regulation can be switched to external temperature with just one key. Push and turn buttons allow for intuitive menu navigation. The menu comes in different languages. With the innovative WiCo Wireless Controller, the unit can be operated from a distance of up to 10 meters/3 feet. All IKA baths conform to the highest safety classification III (FL) for use with flammable liquids according to DIN 12876. IC control immersion circulators allow for quick heat up times and stable temperature conditions. With integrated connections (M16x1) the device is suitable for external applications.
- Temperature range: RT – 250 °C
- Temperature stability: ± 0.01 K
- Stainless steel bath bridge can be combined with water baths of different volumes
- Wireless control enables safe operation, e.g. outside of a closed fume hood
- Powerful pressure/suction pump
- Adjustable safety circuit
- Large easy to read TFT display for temperature, pump speed, liquid level and safety temperature
- Electronic timer function: 0 – 99 h 59 min
- Visual and acoustic safety warnings
- Connection of a magnetic valve possible
- USB / RS 232 interface for PC control, documentation using labworldsoft®, as well as updating the device software through our website
Scope of delivery
- Hose olive NW 12 (2 pcs.)
- CC1
- Screwdriver
- OS 1.0 power supply (for WiCo)
- USB Cable - USB A to Micro-B, 2 m
- USB 2.0 cable Micro A – Micro B
About IKA
Founded in 1910 as a supplier for pharmacies and hospitals, the company left bombed-out Cologne for Staufen im Breisgau in 1942. There it quickly became the world's leading company for laboratory technology as well as dispersing, stirring and kneading machines.
Technical Data of IKA IC Temperature Control
| Appliance type | Immersion thermostat |
| Class designation acc. DIN 12876 | III |
| Identification according to DIN 12876 | FL |
| Heat output | 1250 W |
| Working temperature | room temp. +10K @1000rpm - 250 °C |
| Operating temperature min. (with external cooling) | -20 °C |
| Temperature display | yes |
| Temperature control | PT 100 |
| Working temperature sensor | PT 100 |
| Safety temperature sensor | PT1000 |
| Working temperature display | TFT |
| Safety temperature display | TFT |
| Temperature stability DIN 12876 | ±0.01 K |
| Connection for ext. temperature sensor | PT 100 |
| Display resolution | 0.01 K |
| Display for operation with ext. sensor | yes |
| Set temperature resolution | ±0.1 K |
| Warning function optical | yes |
| Warning function acoustic | yes |
| Warning function excess temperature | yes |
| Adjustable safety circuit | 0 - 260 °C |
| Sub-level protection | yes |
| Over-level protection | yes |
| Pump type | Pressure- / suction pump |
| Pump capacity adjustable | yes |
| Pump pressure max. (0 liters discharge flow) | 0.61 bar |
| Pressure pump (suction side) (0 liter flow) | 0.45 bar |
| Flow rate max. (0 bar back pressure) | 31 l/min |
| Pump connection | M16x1 |
| Cooling coil connection | NW 8 |
| Bath depth min. | 150 mm |
| Calibration option | yes |
| Appliance fastener | Bridge |
| Range of universal clamp | 280 - 375 mm |
| Technical data complies with the standard | DIN 12876 |
| Permissible ON time | 100 % |
| Multi-Interface | yes |
| Alarm output (potential-free contact) max. | 30 V AC/DC |
| Alarm output (potential-free contact) max. | 1 A |
| Solenoid valve output | 24 VDC |
| Solenoid valve output max. | 0.8 A |
| Standby input | 5 VDC |
| Dimensions (W x H x D) | 285 x 313 x 291 mm |
| Weight | 11 kg |
| Permissible ambient temperature | 5 - 40 °C |
| Permissible relative humidity | 80 % |
| Protection class according to DIN EN 60529 | IP 21 |
| RS 232 interface | yes |
| USB interface | yes |
| Voltage | 100 - 115 V |
| Frequency | 50/60 Hz |
| Power input | 1400 W |
