MSE PRO Advanced Trinocular Inverted Metallurgical Microscope (Bright Field and Dark Field, with ECO Function)

MSE PRO Advanced Trinocular Inverted Metallurgical Microscope (Bright Field and Dark Field, with ECO Function)

SKU: OM0037

  • $ 5,65995
  • Save $ 62900

MSE PRO™ Advanced Trinocular Inverted Metallurgical Microscope (Bright Field and Dark Field, with ECO Function)

  • Independent metallographic detecting system
  • Visual system for large-scale equipment
  • Long working distance metallurgical objectives

Specifications:

Item Specification OM0037
Optical System Infinite Color Corrected Optical System ●
Viewing Head 30° inclined gemel trinocular head, 360° rotatable, interpupillary distance 54-75mm, visual adjustment: ±5 diopter, splitting ratio binocular: trinocular =100:0 or 50:50 ●
Eyepiece High eye point wide field plan eyepiece PL10X/22mm ●
High eye point wide field plan eyepiece PL10X/22mm, with micrometer ○
High eye point wide field plan eyepiece PL10X/22mm, with adjustable diopter ○
High eye point wide field plan eyepiece PL10X/22mm, with micrometer and adjustable diopter ○
High eye point wide field plan eyepiece PL10X/23mm, with adjustable diopter ○
High eye point wide field plan eyepiece PL15X/16mm ○
Objective Infinity Long Working Distance Bright Field Plan Achromatic Metallurgical Objectives 5X/NA=0.15, WD=10.8mm ○
10X/NA=0.3, WD=12.2mm ○
20X/NA=0.45, WD=4.0mm ○
50X/NA=0.55, WD=7.9mm ○
100X/NA=0.8, WD=2.1mm ○
Infinity Long Working Distance Bright & Dark Field Plan Achromatic Metallurgical Objectives 5X/NA=0.15, WD=9.0mm ●
10X/NA=0.3, WD=9.0mm ●
20X/NA=0.45, WD=3.4mm ●
Infinity Long Working Distance Bright & Dark Field Semi-Apochromatic Metallurgical Objective 50X/NA=0.55, WD=7.5mm ●
100X/NA=0.8, WD=2.1mm ○
Nosepiece Inward quintuple bright & dark field nosepiece, with DIC slot ●
Microscope Body Coaxial focusing mechanism with a column hole diameter of 32mm, coarse range: 45mm, fine precision: 0.002mm, with upper limited and tension adjustment. ●
Large flat base ○
Column type large flat base, base size: 320*260*16mm (excluding feet), equipped with seismic resistant feet. Installation holes on the base for movable stage. ●
Illumination With variable aperture and field diaphragm, both center adjustable. With switch device between bright field and dark field. For single fiber optic lighting ●
Fiber optic adapter kit ●
Power box (black) of high brightness LED cold color lamp, input 85-265V/AC, output 20W. LED color temperature 6000K. ●
Single fiber tube (length: 0.55m) ●
Single fiber tube (length: 1m) ○
Single fiber tube (length: 1.5m) ○
Polarizer and Analyzer Polarizer and fixed analyzer ○
Polarizer and 360-degree rotatable analyzer ●
Filters Blue interference filter for reflected use: <480nm ○
Green interference filter for reflected use: 520nm-570nm ○
Red interference filter for reflected use: 630nm-750nm ○
Interference filter for reflected use, color balance plate (white light) ○
C-mount Adapter 0.35× C-mount adapter, focus adjustable ○
0.5× C-mount adapter, focus adjustable ○
0.65× C-mount adapter, focus adjustable ○
1× C-mount adapter, focus adjustable ○
Other Accessories DIC Kit, for infinity LWD BD plan achromatic metallurgical objectives and infinity LWD BD semi-apochromatic metallurgical objectives ○
High precision micrometer, 0.01mm increment ○
Ordinary micrometer, 0.01mm increment ○
Internal hexagonal Spanner M3 ●
Internal hexagonal Spanner M4 ●

Note: ●Standard parts,  ○Optional parts
