MSE PRO Automated Tissue Grinder and Homogenizer
SKU: MA1022
MSE PRO™ Automated Tissue Grinder and Homogenizer
This automated tissue grinder is used by laboratories handling of high-throughput plant and animal tissue samples to reduce hands-on preparation time and also reduce the potential of sample contamination. It utilizes a method of homogenization which occurs through vertical motion of beads in the sample tube that mechanically disrupt the tissue for DNA, RNA, and protein extraction.
MA1022: Does not have temperature control feature.
MA1023: Allows for temperature control between -50°C and 0°C
Features
- Handles up to 48 2mL samples or 12 5mL samples at a time.
- Utilizes a steel ball that is added to the sample vial (tank or tube) that vibrates vertically for quick and successful tissue homogenization.
- Can perform dry or wet grinding for mixing and homogenization.
- High-throughput sample volumes for grinding up to 4x96 samples at once within as little as 3 minutes.
- Typical sample types include plant tissue, animal tissue, cells, bacteria, yeast, and herbs.
Specifications
| SKU # | MA1022 | MA1023 | MA1024 |
| Power Supply (V/Hz) |
110/60 | 110/60 | 110/60 |
| Rated Power (W) |
180 | 375 | 375 |
| Timer Setting (Sec.) |
1-9999 | 1-9999 | 1-9999 |
| Frequency Setting |
10-20Hz ~ 300-2100 rev./min. |
10-70Hz ~ 300-2100 rev./min. |
10-70Hz 270-2000 rev./min |
| Clamp Stroke (mm) | 34 (Vertical) | 34 (Vertical) | 30 (Vertical) |
| Sample Capacity |
2mL Adapter for 48 Samples 5mL Adapter for 12 Samples |
2mL Adapter for 48 Samples
Optional: 5mL 24 Sample or |
1-2mL Adapter for 2*48 Samples .2-.5mL Adapter for 2*96 Samples 5mL Adapter for 2*24 Samples |
| Display | 7in. TFT Touch Screen | 5.7in TFT Touch Screen | Digital Control |
| Protection | Open Lid Protection with Emergency Brake | Open Lid Protection with Emergency Brake | Open cover Protection with Emergency Brake |
| Dimensions LxWxH (mm) |
369x360x520 | 450x460x795 | 514x380x520 |
Items Included / Packing List
| MA1022 | MA1023 | MA1024 | |
| Part Description | Quantity | Quantity | Quantity |
| Tissue Grinder | 1 | 1 | 1 |
| Adapters |
2mL: 48 Samples 5mL: 12 Samples |
2mL: 48 Samples 5mL: 12 Holes |
2mL: 2*48 Samples .2-.5mL: 2*96 Samples 5mL: 2*24 Samples |
| Stanless Stell Grinding Beads |
2 Bottles of 6mm (500 pieces) 1 Bottle of 3mm (500 pieces) |
2 Bottles of 6mm (500 pieces) 1 Bottle of 3mm (500 pieces) |
1 Bottle of 3mm 1 Bottle of 6mm |
| Power Cord | 1 | 1 | 1 |
| User's Manual | 1 | 1 | 1 |
