Resistivity/Conductivity Analysis and Testing Services

Resistivity/Conductivity Analysis and Testing Services

SKU: RESTVT001

  • $ 14295
  • Save $ 1600



Resistivity/Conductivity Analytical Service is suitable for measuring conductivity-related properties of materials, including resistivity, sheet resistance, surface resistance, resistance, and contact resistance. Applicable material forms include solids, thin films, coatings, powders, and liquid slurries.

Testing Range:

  • Low-Resistance Meters: Typically used for testing conductive materials such as metals, graphene, and graphite with resistance <100 kΩ.
  • High-Resistance Meters: Used for less conductive materials such as plastics and fabrics, with a resistance range of 100 kΩ to 101410^{14} Ω.

Application Fields:

Semiconductors, lithium batteries, solar cells, fuel cells, new energy technologies, graphite and carbon materials, graphene, ITO films, conductive glass, rubber and plastic materials, insulation, and antistatic industries.

Sample Requirements:

  • Powder Samples: Particles should be as uniform as possible. A mesh size of ≤40 is recommended (finer particles are acceptable), and the maximum size should not exceed 10 mesh. At least 1 mL of sample by volume is required.
  • Bulk/Solid/Thin Film Samples:
    • For conventional low-resistance samples, the length should exceed 1 cm.
    • For high-resistance samples (e.g., antistatic/epoxy materials), vertical bulk resistance requires a diameter >50 mm, and surface resistance requires >80 mm.
  • Liquid Samples: A minimum of 10 mL is required.
  • Gel Samples: If the sample is difficult to remove, the container’s opening should have a diameter >2.5 cm, or the sample should be level with the container opening.
  • Fiber Samples: The recommended length is >3 cm, and the fibers should not be too brittle. Diameter information must be provided.
  • Volume Resistance Testing: The sample surface must be flat and smooth; otherwise, poor contact may result in inaccurate testing results.
  • Battery Bipolar Plates/Carbon Paper: Refer to the instrument details for specific requirements.

Note: The listed price is for reference only. Please request a quote for the final pricing.

Analytical Service Minimum order requirement: $250 per order. A $200 handling fee will be applied if order is below $250.

Please contact sales@msesupplies.com for additional information and instructions on our Analytical Services program. Confirmation of the sample(s) requirements, SDS sheets and additional information is needed prior to processing the Analytical Service order.

***Please do not ship any samples without authorization from MSE Supplies***
