Witeg Baths WCB-H Circulation Head 11/22 Liter 100°C ±0,1°C
SKU: DH.WCB10011
Witeg Baths WCB-H Circulation Head 11/22 Liter 100°C ±0,1°C
Buy Witeg products from MSE Supplies at the best value.
Description
Ideal for
- Multi-use digital precise immersion circulator head
Features
Devices with 230 V power supply can also be supplied with 120 V on request.
Features
- User‘s self-compensation function to control difference between real temperature and indicated temperature (±10.0°C)
- Digital timer function (99hr 59min): delay time and operation time can be controlled
- Powerful circulation pump assures temperature uniformity
- Storage function for the set values of temperature and timer
- Backlight LCD display
- CE certified and unique serial number for tracing
Safety mechanism
- Locking mode
- Over- temperature and over-current protection
- Sensor error detection
- Low water level warning and automatic stop function
Controller
- Digital fuzzy controller with Jog-Shuttle-switch (turn + push)
Technical data
| Width (Outer) | 130 mm |
| Height (outer) | 320 mm |
| Capacity | 11 l |
| Power consumption | 1000 W |
| Temperature accuracy | ±0.1°C |
| Controller | Temperature sensor PT100 |
| Length (outer) | 165 mm |
| Weight with packaging | 8 kg |
| Pump performance | 5 l/min |
| Temperature range | Room temperature +5°C - 100°C |
| Packing size | 400 x 280 x 200 mm |
Comparison
| SKU | Model | Width (Outer) | Length (outer) | Height (outer) | Weight with packaging | Capacity |
| DH.WCB10011 | WCB-11H 230 V | 130 mm | 165 mm | 320 mm | 8 kg | 11 l |
| DH.WCB10022 | WCB-11H 230 V | 130 mm | 165 mm | 320 mm | 10 kg | 11 l |
| SKU | Pump performance | Power consumption | Temperature range | Temperature accuracy | Packing size | Controller |
| DH.WCB10011 | 5 l/min | 1000 W | Room temperature +5°C - 100°C | ±0.1°C | 400 x 280 x 200 mm | Temperature sensor PT100 |
| DH.WCB10022 | 5 l/min | 1000 W | Room temperature +5°C - 100°C | ±0.1°C | 400 x 280 x 200 mm | Temperature sensor PT100 |
