MSE PRO Benchtop Electrode Slitting Machine for Cylindrical and Pouch Cell Battery

SKU: BR0410

  • £6,25100
  • Save £75100



MSE Supplies offers a benchtop electrode slitting machine for cylindrical and pouch cell research. It is designed for slitting the anode and cathode electrode after the calendaring. The blade cutting width is customizable to accommodate the specific electrode width. It also can be used for slitting other soft metallic foils.

MSE Supplies is a US-based leading supplier of battery research materials and equipment with thousands of customers worldwide.

    SKU BR0410
    Maximum Slitting Width 300mm (Customizable)
    Compatible Slitting Material Coated copper/aluminum foil or soft metallic foil
    Slitting Thickness 50~400μm
    Slitting Blade

    58mm wide blade (standard)

    (Blade width is customizable)

    Voltage 110V
    Net Weight 60kg
    Dimension 1050*900*400mm
    Warranty One year limited warranty with lifetime product support
