Antech 13L W Series, Wide-Neck Cryogenic Freezer

SKU: W100-1

  • £11,32700
  • Save £1,25900



Antech 13L W Series, Wide-Neck Cryogenic Freezer

Buy Antech products from MSE Supplies at the best value.

W series liquid nitrogen storage system provides ideal storage conditions for biological samples. Supported by LN2 automatic filling system and temperature & LN2 level monitoring system, W series cryogenic freezers provide all-round protection to precious sample, assisting life science research and cell therapy applications.

Based on the actual needs of users, Antech has innovatively optimized the performance, structure and control system of cryogenic freezer to meet the user's highest standard of large-capacity storage requirements.

  • Multiple capacity freezers, from 175L to 600L, 2.0ml vials storage capacity from 10,000 to 40,500.
  • Excellent temperature uniformity and stability, enabling samples to be stored at controlled cryogenic environment.
  • Excellent vacuum performance and structural design ensure minimum liquid nitrogen consumption and lower storage costs.
  • Advanced temperature, liquid level monitoring and alarm system, and can realize remote monitoring.
  • Automatic supply of liquid nitrogen, safe and labor-saving.
  • The liquid nitrogen supply system is controlled by multiple solenoid valves, which can effectively prevent the overflow of liquid nitrogen and sample contamination caused by high LN2 level.
  • Manual filling available under special circumstances.
  • Compatible with vapor phase and liquid phase storage modes, users can choose according to their needs.
  • The optimized mechanism design realizes high-density storage to save space.

MSE Supplies offers a variety of Antech Products. Please contact us for more information.

Specifications:

SKU# W100
LN2 Capacity 13 L
Inner diameter 550 mm
Usable height
785 mm
Overall height
1300 mm
Weight empty  160 kg
Controller Touch screen
Voltage 110 V / 60 Hz



Maximum Storage Capacity:

Model W100 W240 W380
Maximum storage capacity  Liquid Vapor Liquid Vapor Liquid Vapor
Straw PETG 1/4cc straw 180400 144320 397700 318160 639600 511680
PETG 1/2 cc straw 80300 64240 177025 141620 284700 227760
HSV CBS high security straws 80300 64240 177025 141620 284700 227760
High security   CBS straws 49500 39600 109125 87300 175500 140400
Number of canisters (φ70mm)  44 44 97 97 156 156
Goblet (φ65mm)  per canister 5 4 5 4 5 4
2ml vial 1.2 &2ml vial 10725 9900 26325 24300 41275 38100
Number of large rack (81/100-place box)  7 7 19 19 30 30
Number of small rack (25-place box)  5 5 5 5 7 7
2" Boxes per rack 13 12 13 12 13 12
5ml vial 5ml vial (81-place) 3969 3402 10773 9234 17010 14580
Number of racks 7 7 19 19 30 30
3.75" Boxes per rack 7 6 7 6 7 6
25ml blood bag
    (Pall MEDSEPTM 25 mL, OriGen CS 25)
Numbers of blood bag 763 763 1694 1694 2681 2681
Number of frames 109 109 242 242 383 383
Bags per frame 7 7 7 7 7 7
50ml blood bag
    (Fenwal 4R9951, OriGen CS 50)
Numbers of blood bag 476 476 1085 1085 1715 1715
Number of frames 68 68 155 155 245 245
Bags per frame 7 7 7 7 7 7
250ml blood bag
    (Fenwal 4R9953 & 4R5461, OriGen CS 25 or CryoMACS 50 & 250)
Numbers of blood bag 270 216 595 476 970 776
Number of frames 54 54 119 119 194 194
Bags per frame 5 4 5 4 5 4
500ml blood bag
    (Fenwal 4R9955 & 4R5462, OriGen CS 500)
Numbers of blood bag 210 168 475 380 760 608
Number of frames 42 42 95 95 152 152
Bags per frame 5 4 5 4 5 4
200ml blood bag
    (Gambro DF-200 or CryoMACS 50 & 250)
Numbers of blood bag 144 144 332 332 528 528
Number of frames 36 36 83 83 132 132
Bags per frame 4 4 4 4 4 4
700ml blood bag
    (Gambro DF-700, OriGen CS 1000 or CryoMACS 500& 750 &1000)
Numbers of blood bag 84 84 196 196 312 312
Number of frames 21 21 49 49 78 78
Bags per frame 4 4 4 4 4 4
