MSE PRO Low Temperature Freezer, -25 ℃ ~ -5 ℃

MSE PRO Low Temperature Freezer, -25 ℃ ~ -5 ℃

SKU: LS1813

  • £22,46600
  • Save £1,62700

MSE PRO™ Low Temperature Freezer, -25 ℃ ~ -5℃

The MSE PRO™ Low Temperature Freezer can provide safe and high-speed cooling rates to meet the needs of liquid refrigeration. It is suitable for high-tech industries such as medical, biochemical, pharmaceutical, freeze-drying, petrochemical, and semiconductor, etc.

  • Secondary Supercooling Technology: Adopting secondary supercooling technology, rapid cooling.
  • Whole Machine Installation: Users only need to install refrigerant and cooling water.
  • Automation Operating System: It can display temperature curves and export temperature records.
  • Saving Resources: The refrigeration unit is controlled by a semi-hermetic screw compressor and electronic expansion valve, which is highly efficient and energy-saving.
  • Factory Testing: Each machine undergoes a load test of no less than 12 hours before leaving the factory.

Brand: MSE PRO™

Manufacturer: MSE Supplies LLC

MSE Supplies offers a variety of Low Temperature Freezers. Please contact us for more information.

Specifications:

SKU# LS1813
Medium Temperature Range -25 °C ~ -5 °C
Temperature Sensor PT-100
Cooling Capacity 12 KW (-20 ℃), 10320 Kcal/h
Circulation Pump 6.6m³/h, 1.2bar
Inlet & Outlet Connector Size DN25
Coiling Water At 30℃ 8m³/h, DN40
Expansion Tank (Standard) 100 L
Evaporator Plate Heat Exchanger
Operating Controller 7-inch color touch screen, Temperature curve record
Refrigerants R-404A / R23 / R14
Heat Transfer Fluid
 Non-corrosive liquid, Ethanol, Ethylene glycol, Silicon Oil
Security Protection High voltage protection; Water cut protection; Over current protection; Leakage protection; Phase sequence protection; High temperature protection; Sensor failure and low level alarm, etc.
Fluid Level Indication Glass Fluid Level Gauge
Pipeline Material Expansion tank, cold storage tank and circulating pipeline are all made of SUS304.
Product Size 1000 x 1500 x 1850 mm
Weight 800 kg
Voltage 380 V / 50 Hz
dB Within 75dB
Case Material Steel Channel + Square Tube + Cold Rolled Steel (7035)
